To handle turnover correctly, we need to add to our instructions above for turning the rotors, based on the letters showing in line with the grey bars:

In the example above we chose the message key A B C with a short message so that no turnovers occurred. When the right-hand rotor turns one step, at some positions other rotors turn over as well, which makes the scrambling harder to predict. If you got it right, you should have written down one correct English word!

Write down the letter at which you end up.

Find the letter from your message on the Input/Output cylinder at the right-hand side, and trace the line from it through all three rotors, in to the reflector, out again back through all three rotors and into the Input/Output cylinder again.

You must do this before you read off the letter (even the first one!)

Turn just the right-hand rotor one step towards you (so the letter in line with the grey bar becomes the next one alphabetically) make sure that the other rotors and the Input/Output cylinder stay still.

Turn the rotors so that the three letters of your message key are in line with the grey bars for practice use A B C.

Make sure that the grey bars on the Reflector and the Input/Output cylinders line up this shows the start position of your Enigma machine and lets you track the turnover positions of the rotors.

You can start with the basic Enigma machine (using three rotors with ring settings of 01 01 01) using just the 5 pieces shaded in this diagram: The templates use colour to help you follow the lines, but this is not essential and you can print them in black-and-white if you like. Scaling may be set to "Fit to printable area" by default you should set it to "None".

#TWO ROTOR ENIGMA SIMULATOR SOFTWARE#

Using low-tack "removable" sticky tape can make it easier to swap round and reuse the rotors if you want to do that, but it's not essential.īefore you print the templates, please make sure you turn off any scaling options in your printer software so that it is printed at the exact size required.

#TWO ROTOR ENIGMA SIMULATOR PDF#

The submarine command Engima was notably the most secure and eluded being code broken until even the internal German high command Enigma had been broken wide open.You will need these PDF templates printed on to 2 A4 sheets of paper, a crisp tube (75mm in diameter and at least 225mm long), clear sticky tape and a pair of scissors.

The initial 3 rotor and the late war 5 rotor + plugboard were totally different animals from the perspective of a codebreaker. The training given to operators on the method of operation of the Enigma machine was different between each branch of the German military, which also would change occasionally, and the Engima machine itself was updated throughout the war. The British-Polish team at Bletchly Park was able to exploit them to figure out the internal electrical diagrams of the rotors and use methods & early computers developed by Alan Turing to decrypt encrypted messages without a single machine ever having been captured.ĮDIT: This is a substantial simplification. Mathetmatically, the system had several flaws that could be exploited. This book was fragile, exceptionally flammable, and the wording was printed in ink that would immediately vanish if you poured water on the book.Įvery service (army, navy, submarines, air force) were given incompatible rotors with different wiring.

As long as both the transmitter and the receiver started with the same rotor positions, it could be enciphered and deciphered. This book would tell you pre-scheduled initial rotor positions. Essentially, both sides of the transmission were given a book.
